Advanced Control Suite User’s Guide
57
as shown in Figure 32.
Figure 32. VLAN Name Selected
2. Click the Vital Sign tab to view the properties of the VLAN adapter.
3. Click the BASP Statistics tab to view the statistics for the VLAN
adapter.
4. Click the Network Test tab to run a network test on the VLAN adapter.
To delete a VLAN, perform the following procedure.
1. In BACS2, select the VLAN name in the team’s Virtual Adapters folder,
as shown in Figure 32 on page 57.
2. Right-click the VLAN name and select click Remove VLAN.
3. Click Apply.
4. Click Yes when you see the message indicating that the network
connection will be temporarily interrupted.
Note
When you delete a team, the VLANs configured for that team are
also deleted.
