Advanced Control Suite User’s Guide
17
Information
Provided by the
BACS 2
Applications
The Broadcom Advanced Control Suite 2 lists all of the network adapters
in your computer and provides the following information, if available, about
each device, as shown in Table 1.
BACS 2 Features
The following features are accessible from the BACS 2 application:
ˆ “Vital Sign Tab” on page 23. Provides at-a-glance status reports on all
of the LAN devices in your computer.
ˆ “Resources Tab” on page 25. Displays the system resources of the
selected device.
ˆ “Hardware Tab” on page 26. Displays the hardware information (the
ASIC version and the firmware version) for the selected device.
ˆ “Advanced Tab” on page 27. Allows you to change the advanced
properties.
ˆ “Network Test Tab” on page 31. Confirms network connectivity to a
remote station. The network test sends ICMP packets to remote
systems and waits for a response. If a gateway is configured, the test
automatically sends packets to that system. If a gateway is not
configured or if the gateway is unreachable, the test prompts you for a
destination IP address.
ˆ “Diagnostics Tab” on page 31. Performs comprehensive diagnostics
on Broadcom network adapters.
ˆ “Statistics Tab” on page 34. Provides detailed performance statistics
on each selected device.
Table 1. BACS Application Information
Driver Status Driver Version Frames Rx OK
MAC Address Driver Date Team Name
Link Status Firmware Version Team Type
IP Address ASIC Version VLAN Name
Memory Address Bus Type VLAN ID
Physical Address Bus No. BASP Tx Packet
Speed Device No. BASP Tx Packet
Discarded
Duplex Function No. BASP Tx Packet
Queried
Slot No. Interrupt Request BASP Rx Packet
Driver Name Frames Tx OK BASP Rx Packet
Discarded
