Chapter 6: Setting Advanced Properties
72
4. From the Value list on the Advanced tab, select one of the following:
None - Disables checksum offloading.
Rx TCP/IP Checksum - Enables receive TCP, IP, and UDP
checksum offloading.
Tx TCP/IP Checksum - Enables transmit TCP, IP, and UDP
checksum offloading.
Tx/Rx TCP/IP Checksum (default) - Enables transmit and receive
TCP, IP, and UDP checksum offloading.
5. Click OK.
6. If prompted to restart your computer, click Yes.
Although it is not necessary to reboot the system for new adapter
properties to take effect, rebooting is recommended to reinitialize all
registers.
7. Verify that the port LED operates as described in “Physical
VLAN ID
The VLAN ID specifies the VLAN identifier. It is the number of the VLAN
where the port is an untagged member. You must assign a VLAN ID to a
VLAN. The range is 1 to 4094. The default VLAN has a VLAN ID of 0.
To assign a VLAN ID, do the following:
1. Access the Device Manger for your operating system.
To access the Windows XP Device Manager, see “Selecting the
Device Manager Window” on page 47.
To access the Windows Vista Device Manager, see “Selecting the
Device Manager” on page 39.
To access the Windows 7 Device Manager, see “Selecting the
Device Manager Window” on page 54.
2. Click the Advanced tab.
The Advanced tab is shown in Figure 31 on page 64.
3. Under Property list on the Advanced tab, select VLAN ID.
4. From the Value list on the Advanced tab, choose a VLAN ID from 1 to
4094.
Note
The default VLAN has a VLAN ID of 0.
