Chapter 2: Installation
42
4. Slide the SFP transceiver into the SFP slot on the switch, as shown in
Figure 9. Inserting the SFP
Note
SFP transceivers are dust sensitive. When a fiber optic cable is not
installed, or when you store the SFP, always keep the plug in the
slot. When you do remove the plug, keep it for future use.
Note
Unnecessary removal and insertion of an SFP can lead to
premature failure.
For information about cabling for the SFP, refer to “Cabling an SFP
Transceiver” on page 44.
