Allied Telesis AT-GS950/16PS - Manual (Page 139)

AT-GS950/16PS Switch Web Interface User’s Guide
139
9. The IGMP Snooping Page is updated with active Multicast Group
address. See Figure 45.
Note
The Multicast Group Address table contains MAC addresses of
nodes that are active members of multicast groups. To set a static
Multicast Group Address, see “Static Multicast Address
Configuration” on page 130.
Figure 45. IGMP Snooping Page with MAC Addresses
10. To display ports that are members of the multicast group address, click
on the MAC address.
11. From the main menu on the left side of the page, select Save
Configuration to Flash to permanently save your changes.
