AFX LW217WAR8 User Manual
Linear fluorescent wrap

For 2 or 4 lamp 17watt F17T8, 25watt F25T8 or 32watt F32T8
Make sure that the power source conforms to the
requirements of the fixture.
(See labels on fixture housing).
Questions, problems, missing parts? Before returning to your
retailer, call our customer service department at
3
4
Wire nuts
Mounting screws or Toggle bolts
Ballast cover
D
Wood endcaps with screws
Description
Quantity
1
Channel assembly
A
C
B
Diffuser
1
1
1-800-873-2326, 8 a.m.-4 p.m., CST, Monday-Friday.
PACKAGE CONTENTS
Description
Part
LINEAR FLUORESCENT WRAP
ADDITIONAL PARTS REQUIRED
(not provided)
OPTIONAL (provided with LWK & PLWK)
2
Quantity
232 model shown
•
•
•
•
•
•
•
•
Tools Required for Assembly: Eye protection, screwdriver, ladder.
Before beginning installation of product, make sure all parts are present. Compare parts with package contents list and diagram
above. If any part is missing or damaged, do not attempt to assemble, install or operate the product. Contact customer service
for replacement parts.
WARNINGS AND CAUTIONS
Read all safety precautions and installation instructions carefully before installing or servicing this fixture. Failure to comply
with these instructions could result in potentially fatal electric shock and/or property damage.
It is recommended that a qualified electrician perform all wiring. This fixture must be wired in accordance with all national
and local electrical codes.
To reduce the risk of electrical shock, and to assure proper operation, this fixture must be adequately grounded.
Do not handle any energized fixture or attempt to energize any fixture with wet hands or while standing on a wet or damp
surface or in water.
Disconnect electrical power before installing or servicing any part of this fixture.
Not for use with dimmer switch of any kind. (except for D10 models)
CAUTION
PREPARATION
WARNING
We hereby warranty that this fixture is free from defects in materials and workmanship when installed and used
under normal operating conditions for a period of 2 years from date of purchase. This warranty covers all component
parts and extends only to replacement of defective fixture or components; it does not cover failure due to improper
installation, misuse, mishandling or damage incurred in transit.
Limited Factory Warranty
4
Mounting screws or Toggle bolts
2 or 4
1
T8 Fluorescent lamps only
Electrical tape
Helpful Tools: Wire cutter, pliers, stud finder, wire stripper, drill with 1/4 in. bit.
Estimated Assembly Time:
20
minutes
8060318 Rev 2
