AXIS Q7406 Installation Guide
Hardware overview
Dimensions
30 x 130 x 255 mm (1.2” x 5.1” x 10.0”) excluding connectors.
6 Video inputs
S/N & P/N label
Bus connectors
DIP switches
1 2 3 4 5 6
D I
ON
P
POWER
1
2
3
4
5
6
Control button
Video inputs 1-6
Power LED
Status LEDs 1-6
Reset button
