Page 14 AXIS Q7406 Installation Guide
Pin assignments
Pin assignments for the I/O Connector of the AXIS 291 1U Video Server Rack
Pin Function Description
1 +12V out, 100mA
2 GND
3 Channel 1, Configurable I/O 1 Digital input - Connect to GND to
activate, or leave floating (or
unconnected) to deactivate.
Digital output - Uses an open-
drain NFET transistor with the
source connected to GND. If used
with an external relay, a diode
must be connected in parallel
with the load, for protection
against voltage transients.
Min input = - 40V DC
Max input = + 40V DC
Max load = 100mA
Max voltage = + 40V DC
(to the transistor)
4 Channel 2, Configurable I/O 1
5 Channel 3, Configurable I/O 1
6 Channel 4, Configurable I/O 1
7 Channel 5, Configurable I/O 1
8 Channel 6, Configurable I/O 1
9 Channel 1, Configurable I/O 2
10 Channel 2, Configurable I/O 2
11 Channel 1, RS485A
(non-inverting) (Video input 1) A half-duplex RS-485 interface for controlling auxiliary equipment
e.g. PTZ devices.
12 Channel 1, RS485B
(non-inverting) (Video input 1)
