Product Specifications
LOOP INTERFACE
■ Modulation Type: 2B1Q
■ Mode: Full duplex, echo cancelling
■ Number of pairs: Two
■ Bit Rate: 784 kbps per pair
■ Baud Rate: 392 kbps per pair
■ Service Range: Defined by CSA guidelines
■ Loop Loss: 36 dB maximum @ 200kHz
■ Bridged Taps: Single Taps <2 kft, total taps
≤
2.5 kft
■ Performance: Compliant with Bellcore
TA-NWT-001210
■ HDSL Tx Signal Level: 13.5 dBm
■ Imput Impedance: 135
Ω
■ Return Loss: 20 dB (40 kHz to 200 kHz)
DIAGNOSTICS
■ Local loopback (HTU-C)
■ Remote loopback (HTU-R)
■ Troubleshooting screen
MOUNTING
■ Litespan 2000 DBA, Litespan 2012 CBA, or
an ONU CBA
ENVIRONMENT
■ Operating (standard): –40° to 70°C
■ Storage Temperature: –40° to 85°C
PHYSICAL
■ Dimensions: 4.42" H, 0.84" W, 10.4" D
■ Weight: Less than one pound
■ Humidity: Up to 95% non-condensing
POWER
■ Max Power Dissipation HTU-C and
HTU-R: < 4 watts
■ Span Power: –135 VDC internally
generated from the –48 VDC
Ordering Information
EQUIPMENT PART #
AHT1U HTU-C for DSC Litespan
AHT1U Narrowband
Wideband Wiring................................1245002L6
Call for individual module information.
Specifications subject to change without notice.
