Diagnostics screen – American Power Conversion XR User Manual
Page 24
Operation – Navigation
16
Smart-UPS® VT 10-30 kVA, 208/220 V and XR Battery Enclosure Operation Manual 990-1599B
Diagnostics screen
From the Diags screen on the Main Menu, you can view the information given on failures for use in
troubleshooting.
• From the Main Menu, select Diags, and press ENTER
• Use UP/DOWN arrow to select Fault and Diagnostics and press ENTER
Note
For more details on Fault and Diagnostics screens, see the Troubleshooting section.
Control
Status
Setup
Logging
Display
Diags
Help
Main Menu
