Samsung BD-HM57C-ZA - Manual (Page 13)

13
- Navigation Sound Effects : When you choose
a menu navigation selection, a Navigation
Sound Effect may sound. Navigation Sound
Effects are different on each Blu-ray Disc.
✎ NOTES
■
Be sure to select the correct Digital Output
or you will hear no sound or just loud noise.
■
If the HDMI device (AV receiver, TV) is
not compatible with compressed formats
(Dolby Digital, DTS), the audio signal
outputs as PCM.
■
Regular DVDs do not have BONUSVIEW
audio and Navigation Sound Effects.
■
Some Blu-ray Discs do not have BONUSVIEW
audio and Navigation Sound Effects.
■
If you play MPEG audio soundtracks, the
audio signal outputs as PCM regardless
of your Digital Output selections (PCM or
Bitstream).
■
If your TV is not compatible with compressed
multi-channel formats (Dolby Digital, DTS),
the player may output PCM 2ch downmixed
audio even though you selected Bitstream
(either Re-encoded or Unprocessed) in the
setup menu.
■
If your TV is not compatible with PCM
sampling rates over 48kHz, the player may
output 48kHz downsampled PCM audio
even though you set PCM Downsampling
to Off.
pCM downsampling
Lets you choose to have 96KHz PCM signals
downsampled to 48KHz before they are
outputted to an amplifier. Choose On if your
amplifier or receiver is not compatible with a
96KHz signal.
dynamic Range Control
Lets you apply dynamic range control to
Dolby Digital, Dolby Digital Plus, and Dolby
True HD audio.
disconnect any wired network connection
before you begin.
To begin configuring your network connection,
follow these steps:
Wired Network
Ğ Wired - Automatic
1. In the Home screen, select Settings,
and then press the v button.
2. Select Network, and then press the v
button.
3. Select Network Settings, and then
press the v button.
4. Select Wired in the Network Settings
screen, and then press the v button.
5. Select Connect button, and then press
the v button. The product detects
the wired connection, verifies the
network connection and then connects
to the network.
Ğ Wired - Manual
If you have a static IP address or the
Automatic procedure does not work, you'll
need to set the Network Settings values
manually.
Follow Steps 1 and 2 in Wired - Automatic,
and then follow these steps:
1. Select Network Status. The player
searches for a network, and then
displays the connection failed message.
2. On the bottom of the screen, select Ip
Settings, and then press the v button.
The IP Settings screen appears.
3. Select the IP Setting field, and then
press the v button.
4. Select Enter manually in the IP Setting
field, and then press the v button.
5. Select a value to enter (Ip Address,
for example), and then press the v
button.
Use the number keypad on your
remote control to enter the numbers
for the value. Use the◀▶ buttons
on the remote control to move from
entry field to entry field within a value.
When done with one value, press the
v button.
6. Press the ▲ or ▼ button to move to
another value, and then enter the
numbers for that value following the
instructions in Step 5.
7. Repeat Steps 5 and 6 until you have
filled in all values.
✎ NOTES
■ You can get the Network values
from your Internet provider.
8. When finished entering all the values,
press the RETURN or EXIT button. The
player verifies the network connection
and then connects to the network.
Wireless Network
You can setup a wireless network
connection in four ways:
- Wireless Automatic
- Wireless Manual
- WPS(PBC)
- WPS(PIN)
When you configure the wireless network
connection, any wireless network devices
currently connected through the player
or, if applicable, the player's current wired
connection, will be disconnected.
● Auto : Automatically controls the dynamic
range of Dolby TrueHD audio, based on
information in the Dolby TrueHD soundtrack.
Also turns dynamic range control on for
Dolby Digital and Dolby Digital Plus.
● Off : Leaves the dynamic range uncompressed,
letting you hear the original sound.
● On : Turns dynamic range control on for all
three Dolby formats. Quieter sounds are
made louder and the volume of loud sounds
is reduced.
downmixing Mode
Lets you select the multi-channel downmix
method that is compatible with your stereo
system. You can choose to have the player
downmix to normal stereo or to surround
compatible stereo.
Network Settings
When you connect this player to a network,
you can use network based applications and
functions such as BD-LIVE, and upgrade
the player's software through the network
connection. For more information, see pages
21~23. Instructions for configuring the network
connection start below.
Configuring your Network
Connection
Before you begin, contact your ISP to find
out if your IP address is static or dynamic. If it
is dynamic, and you have a wired or wireless
network, we recommend using the Automatic
configuration procedures described below.
If you are connecting to a wired network,
connect the player to your router using a
LAN cable before you start the configuration
procedure.
If you are connecting to a wireless network,
