Scan features

219

4. Special Features

The IP address for WSD printer is http://IP address/ws/ (example: http://
111.111.111.111/ws/).

If no WSD printer is displayed in the list, click

The printer that I want

isn't listed > Add a printer using a TCP/IP address or hostname and
select Web Services Device from Device type

. Then enter the printer's

IP address.

4

Follow the instructions in the installation window.

Scanning using the WSD feature

1

Make sure that the machine is connected to your computer and
powered on.

2

Place a single document face down on the document glass, or load the
documents face up into the document feeder (see "Loading originals" on
page 47).

3

Select (Scan) > Scan to WSD on the control panel.

If you see Not Available message, check the port connection. Or check the
printer driver for WSD is correctly installed.

4

Select your computer name from WSD PC List.

5

Select the option you want and press OK.

6

Scanning begins.

22

Scanning to FTP/SMB server

This feature may not be available depending on model or optional goods
(see "Features by models" on page 7).

Setting up an FTP/SMB server

1

Access the SyncThru™ Web Service (see "Using SyncThru™ Web Service"
on page 240).

2

Select Address Book > Individual > Add.

3

Check the box next to Add FTP or Add SMB.

4

Enter the IP address in dotted decimal notation or as a host name.

5

Enter the server port number, from 1 to 65535.

6

Check the box next to Anonymous, then the server permits the access
of unauthorized people.
