《8》
Bottom / 5-function button
Voice memo / Voice Recording / Up button
Flash /
Left button
Menu / OK button
Self-timer /
Right button
Macro / Down button
Play & Pause button
■ Self-timer lamp
Icon Status Description
- For the first 7 seconds, the lamp blinks at 1 second intervals.
- For the final 3 seconds, the lamp blinks quickly at 0.25-
second intervals.
For the 2 seconds, the lamp blinks quickly at 0.25-second
intervals.
A picture will be taken after about 10 seconds and 2
seconds later a second picture will be taken.
Blinking
Blinking
Blinking
■ Camera Status Lamp
Status Description
Power on
The lamp turns on and off when the camera is
ready to take a picture
After taking a picture
The lamp blinks while saving the image data and
turns off when the camera is ready to take a picture
The lamp lights up
(LCD monitor turns off after initializing the device)
Transmitting Data with a PC The lamp blinks (LCD monitor turns off)
The lamp is off
When the printer is printing The lamp blinks
When the USB cable is
inserted to a PC
When the USB cable is
inserted to a printer
Memory card slot Battery holder
Battery chamber cover Battery chamber
Identification of features
