RF401-series and RF430-series Spread Spectrum Radio/Modems
Quiescent Current in Standby Modes*
Avg. Quiescent Current (mA)
Advanced Setup
Standby Mode
Standard
Setup
RF401/
RF411 RF416
RF430/
RF431 RF432
24.0 33.0 26.2 39.8 0 (no duty cycling) 1
3.9 5.5 5.7 9.2 3 2
2.0 2.8 2.4 3.8 4 3
1.1 1.5 1.6 2.4 5
0.64 0.84 1.1 1.5 6
0.40 0.50 0.60 0.75 7 4
* Not receiving a signal nor transmitting
Physical
Size: 12.1 x 7.0 x 3.3 cm (4.75 x 2.75 x 1.3 in)
Weight: 225 g (0.5 lb)
Operating temp. range: –25°C to +50°C
Humidity: 0 to 95% RH, non-condensing
RF/Interface
Transceiver modules: MaxStream
RF401, RF430 – 9XStream XO9-009
RF411, RF431 – 9XStream XH9-009
RF416, RF432 – 24XStream X24-009
Frequency bands: RF401, RF430 – 910.5 to 917.7 MHz
RF411, RF431 – 920.0 to 927.2 MHz
RF416, RF432 – 2.45015 to 2.45975 GHz
Interface ports: CS I/O 9 pin (RF401 series only)
RS-232 9-pin (4 wire: Tx, Rx, CTS, GND)
USB Port (RF430 series only)
RS-232 baud rates: 38.4 k (default), 19.2 k, 9600, 4800, 1200 bps
USB baud rate: 38.4 k (default), 19.2 k, 9600, 4800, 1200 bps;
OS1 only supported 38.4 kbps
Mode: Frequency hopping spread spectrum (FHSS),
25 hop channels, 7 hopping sequences, direct
FM frequency control
Channel capacity: 65,535 addresses
Transmitter output: 100 mW nominal (50 mW RF416, RF432)
Receiver sensitivity: − 110 dBm at 10 -4 bit error rate
(−104 dBm for RF416)
Antenna impedance: 50 Ω, unbalanced (SMA male connector)
Interference reject: 70 dB at pager and cellular phone frequencies
(RF401, RF411, RF430, RF431)
RF packet size: up to 64 bytes, half-duplex
Error handling: RF packet CRC failure detection/rejection or
configurable retry levels
