RF450 Spread Spectrum Radio
3.8 Slave
Radios configured as Slaves in a multi-point network are allowed to
communicate with a multi-point Master (see Figure 3.8-1). The Slave may
communicate with its Master through one or more repeaters.
FIGURE 3.8-1. DevConfig Screen Showing Settings for a Slave in a Multi-Point Network
3.9 Repeater
Setting the Radio Operation Mode to “Multi-Point Repeater” allows the
transceiver to operate as a repeater in a multi-pPoint network. The “Repeaters
Used” box should be checked if there are any repeaters in the network; it
should be set the same for all transceivers in a multi-point network (see Figure
3.9-1).
FIGURE 3.9-1. DevConfig Screen Showing Settings for Repeater in a Multi-Point Network
