Campbell Scientific CS725 Snow Water Equivalency Sensor - Manual (Page 41)

CS725 Snow Water Equivalency Sensor
FIGURE 14-4. CS725 with top cap removed
15. Datalogger CRBasic Programming
15.1 Extended Data Output (.flla) Command
The following program example reads the data values from the CS725 using
the command [.flla].
This program obtains information in addition to reported SWE values such as
radiation counts and other diagnostic information.
'CR1000 Series Datalogger
'Program for CS725 Sensor
'Wiring CS725
'Red - +12VDC
'Black and Clear- G - Ground
'Green RS-232 TX - C2
'White RS-232 RX - C1
'Clear Shield- G – Ground
'Declare Public Variables and alias
Public PTemp As Float,batt_volt As Float
Public Read_CS725_SWE_Flag As Boolean
Public CS725SerialIn As String * 120
Public CS725_COMMAND_String As String * 20
Public CS725_TIME_String As String * 17
Public CS725_Date_Time(5) As Float
33
