CS500 Temperature and Relative Humidity Probe

9

This voltage drop will raise the apparent temperature and relative humidity
because the difference between the signal and signal reference, at the
datalogger, has increased by V

d

. The approximate error in temperature and

relative humidity is 0.35

°C and 0.35% per 100 feet of cable length,

respectively.

7. Absolute Humidity

The CS500 measures the relative humidity. Relative humidity is defined by the
equation below:

RH

e

e

100

s

=

(2)

where RH is the relative humidity, e is the vapor pressure in kPa , and e

s

is the

saturation vapor pressure in kPa. The vapor pressure, e, is an absolute measure
of the amount of water vapor in the air and is related to the dew point
temperature. The saturation vapor pressure is the maximum amount of water
vapor that air can hold at a given air temperature. The relationship between
dew point and vapor pressure, and air temperature and saturation vapor
pressure are given by Goff and Gratch (1946), Lowe (1977), and Weiss (1977).

When the air temperature increases, so does the saturation vapor pressure.
Conversely, a decrease in air temperature causes a corresponding decrease in
saturation vapor pressure. It follows then from Eq. (2) that a change in air
temperature will change the relative humidity, without causing a change in
absolute humidity.

For example, for an air temperature of 20°C and a vapor pressure of 1.17 kPa,
the saturation vapor pressure is 2.34 kPa and the relative humidity is 50%. If
the air temperature is increased by 5°C and no moisture is added or removed
from the air, the saturation vapor pressure increases to 3.17 kPa and the relative
humidity decreases to 36.9%. After the increase in air temperature, the air can
hold more water vapor. However, the actual amount of water vapor in the air
has not changed. Thus, the amount of water vapor in the air, relative to
saturation, has decreased.

Because of the inverse relationship between relative humidity and air
temperature, finding the mean relative humidity is meaningless. A more useful
quantity is the mean vapor pressure. The mean vapor pressure can be
computed on-line by the datalogger (Example 1).

TABLE 5. CR10(X) Wiring for Example 1

Description

Color

CR10(X)

Temperature

Black

SE 3 (2H)

Relative Humidity

Brown

SE 4 (2L)

Signal & Power Reference

Green

G

Power

Red

12 V

Shield

Clear

G
