Appendix A. Daily Average
08: Average (P71)
1: 1
Reps
2: 2*
Loc [ P_const ]
09: If Flag/Port (P91)
1: 10
Do if Output Flag is High (Flag 0)
2: 30
Then
Do
10: Z=X+F (P34)
1: 3*
X Loc [ P_mb_avg ]
2: 800
F
3: 3*
Z Loc [ P_mb_avg ]
11: End (P95)
12: If time is (P92)
1: 0
Minutes (Seconds --) into a
2: 1440
Interval (same units as above)
3: 10
Set Output Flag High (Flag 0)
13: Set Active Storage Area (P80)
1: 1
Final Storage Area 1
2: 10
Array
ID
14: Real Time (P77)
1: 0110
Day,Hour/Minute
15: Sample (P70)
1: 1
Reps
2: 3*
Loc [ P_mb_avg ]
16: Maximize (P73)
1: 1
Reps
2: 10
Value
with
Hr-Min
3: 1*
Loc [ P_mb ]
17: Minimize (P74)
1: 1
Reps
2: 10
Value
with
Hr-Min
3: 1*
Loc [ P_mb ]
-Input Locations-
1 P_mb
2 P_const
3 P_mb_avg
*
Proper entries will vary with program and datalogger channel, and input location assignments.
** With a 21X, use the 5000 mV measurement range.
