CNR1 Net Radiometer
Wiring for Program Example 4
Color Function Example CR23X Program
Channels Used
Red CM3 Up Signal SE1
Blue CM3 Up Reference
White CM3 Down Signal SE2
Black CM3 Down Reference
Grey or Orange CG3 Up Signal SE3
Yellow CG3 Up Reference
Brown CG3 Down Signal SE4
Green CG3 Down Reference
Shield Shield
Pt-100 Temperature Sensor Connections to 4WPB100 and Datalogger
Color Function 4WPB100 CR23X
H 5H
Red Pt-100 Excitation + L 5L
Blue Pt-100 Excitation - G
Yellow Pt-100 Signal + 6H
Green Pt-100 Signal - 6L
;{CR23X}
;
;CNR1 sensitivity for program example = 7.30 uV/W/m^2
;Multiplier for measurement instructions = 1000/7.3 = 136.99
*Table 1 Program
01: 2 Execution Interval (seconds)
;Measure CM3 Up and CM3 Down (shortwave radiation)
;Note: Multiplier (Parameter 6) will be different for each CNR1
1: Volt (SE) (P1)
1: 2 Reps
2: 22 50 mV, 60 Hz Reject, Slow Range
3: 1 SE Channel
4: 1 Loc [ CM3_up ]
5: 136.99 Mult ; mult = 1000/CNR1 sensitivity
6: 0 Offset
;Measure CG3 Up and CG3 Down (longwave radiation)
;Note: Multiplier (Parameter 6) will be different for each CNR1
2: Volt (SE) (P1)
1: 2 Reps
2: 21 10 mV, 60 Hz Reject, Slow Range
3: 3 SE Channel
4: 3 Loc [ CG3_up ]
5: 136.99 Mult ; mult = 1000/CNR1 sensitivity
6: 0 Offset
