6.2.3 Example 3, CR23X Program Using Differential Channels
Program Example 3 requires six differential channels and the 4WPB100
module to measure the four radiation outputs and the Pt-100 temperature
sensor. The program measures the sensors every 2 seconds and calculates and
stores the following data to final storage every 60 minutes:
Array ID
Year
Julian
Day
Hour/Minute
Avg CM3 Up (shortwave radiation)
Avg CM3 Down (shortwave radiation)
Avg CG3 Up (longwave radiation)
Avg CG3 Down (longwave radiation)
Avg CNR1 temperature (degrees C)
Avg CNR1 temperature (degrees K)
Avg Net shortwave radiation
Avg Net longwave radiation
Avg Albedo
Avg Total Net radiation
Avg temperature corrected CG3 Up
Avg temperature corrected CG3 Down
Wiring for Program Example 3
Color Function
Example CR23X
Program
Channels Used
Red CM3 Up Signal 1H
Blue CM3 Up Reference 1L
White CM3 Down Signal 2H
Black CM3 Down Reference 2L
Grey or Orange CG3 Up Signal 3H
Yellow CG3 Up Reference 3L
Brown CG3 Down Signal 4H
Green CG3 Down Reference 4L
Shield Shield
Pt-100 Temperature Sensor Connections to 4WPB100 and Datalogger
Color Function 4WPB100 CR23X
Black Wire EX1
H 5H
Red Pt-100 Excitation + L 5L
Blue Pt-100 Excitation - G
Yellow Pt-100 Signal + 6H
Green Pt-100 Signal - 6L
