CM375 Portable 10-Meter Mast
Step 3: With a rod through the loop or metal ring, pull up on the cable or
threaded rod until the anchor rotates and locks (see FIGURE 3-23).
Anchor
FIGURE 3-23. Locking anchor
Step 4: Fill-in the hole around the cable or threaded rod with loose dirt and
tamp firm.
Step 5: Repeat process for the NE (FIGURE 3-24) and NW anchors.
NE
FIGURE 3-24. Tape measure in slot for Northeast anchor
15
