CM375 Portable 10-Meter Mast
3.2 Assembling Mast Sections .2 Assembling Mast Sections
Step 1: Remove mast sections and other bundled hardware from tote; unzip
and loosen straps (see FIGURE 3-2). Step 1: Remove mast sections and other bundled hardware from tote; unzip
and loosen straps (see FIGURE 3-2).
Sections are numbered for sequential assembly (see FIGURE 3-3). Sections are numbered for sequential assembly (see FIGURE 3-3). NOTE
FIGURE 3-2. CM375 in opened tote
Base
FIGURE 3-3. Mast base, sections, and lightning rod kit
