Met One Rain Gage Models 380 and 385
24”
8”
FIGURE 3-1. Typical Snow Gage Installation
User-Supplied AC Power
Termination Box
User-Supplied AC Power
and Conduit for Heated
Snow Gage
User-Supplied
Concrete Pad
Power Cable
CM240 Mounting Bracket
Level Adjustments
1.5” IPS Pipe
User-Supplied 1” Conduit
for Signal Cable
4
