19 739.704 | 11.10
Load disconnection
SOC control Voltage control
Load disconnection advance
warning
SOC < 40 % < 11.7 V / 23.4 V
Load disconnection SOC < 30 % <11.1 V / 22.2 V
Load reconnection SOC > 50 % >12.5 V / 25.0 V
Bar display scaling
(only in Voltage control with bar display mode)
> 13.0 V / 26.0 V 10 bar segments
> 12.9 V / 25.8 V 9 bar segments
> 12.8 V / 25.6 V 8 bar segments
> 12.7 V / 25.4 V 7 bar segments
> 12.5 V / 25.0 V 6 bar segments
> 12.0 V / 24.0 V 5 bar segments
> 11.7 V / 23.4 V 4 bar segments
> 11.1 V / 22.2 V 3 bar segments
> 11.0 V / 22.0 V 2 bar segments
≤ 11.0 V / 22.0 V 1 bar segment
Mechanical data
Degree of protection IP32
Mounting method Wall mounting
Weight 350 g
Casing Recyclable plastic case
Dimensions L x W x H 187 x 96 x 44 mm
Mounting hole clearances 60 mm vertical, 177 mm horizontal
Connection terminals
(fine / single core) 16 mm 2 / 25 mm 2
AWG: 6 / 4
