14.1.2 Electrical
Table 64: Electrical Specifications
Standard Wide Voltage (V) Wide Voltage with Efficient
Switching Power Supply
(VPT)
Supply Voltage +5Vdc ±0.25V +9V to +15V +9V to +35V
Supply (all pixels off) 16 mA
Supply (all pixels on) 24 mA
14.2 Optical Characteristics
Table 65: Optical Characteristics
Number of Characters 32 (16 characters by 2 lines)
Matrix Format 5 x 8
Display Area 56.0 x 13.8 mm
Character Size 2.67 x 5.01 mm (XxY)
Character Pitch 3.2 mm
Line Pitch 5.35 mm
Dot Size 0.51 x 0.60 mm (XxY)
Dot Pitch 0.54 x 0.63 mm (XxY)
Luminance 350cd/m 2 (100fL) min
Color of Illumination Green
