Parameters Parameter Length Description
speed 1 Hex value corrisponding to a baud
rate.
Description This command sets the RS-232 port to the specified [speed]. The change
takes place immediately. [speed] is a single byte specifying the desired
port speed. Valid speeds are shown in the table below. The display
module can be manually reset to 19,200 baud in the event of an error
during transmission, including transmitting a value not listed below, by
setting the manual override jumper during power up. However, it should
be noted that this command will be ignored until the manual override
jumper is removed again.
Hex Value Baud Rate
53 1200
29 2400
CF 4800
67 9600
33 19200
22 28800
19 38400
10 57600
Remembered Always
Factory Default 19,200 bps
4.4 Setting a Non-Standard Baud Rate
Syntax Hexadecimal 0xFE 0xA4 [speed]
Decimal 254 164 [speed]
Parameters Parameter Length Description
speed 2 Inputed LSB MSB from baud rate
formula (12-2047).
Matrix Orbital PK162-12 16
