G LC 240 64 -GW -V -E
1 2 3 4 5 6 7
Table 74: Part Numbering Scheme
# Desription Options
1 Screen Type G: Graphic
2 Display Technology LC: Liquid Crystal Display
3 Width 240: Pixel Width Count
4 Height 64: Pixel Height Count
5 Colour (Text/Background)
NP: Standard Grey/Yellow-Green
-GW: Grey/White
-WB: White/Blue
6 Input Voltage
NP: Standard (4.75-5.25V)
-V: Extended Voltage (9.00-15.0V)
-VPT: Extended Voltage with ESPS (9.00-35.0V)
7 Temperature
NP: Standard (0 ◦ C to +50 ◦ C)
-E: Extended Temperature (-20 ◦ C to +70 ◦ C)
Table 75: Part Options
15.4 Ordering Information
15.5 Definitions
E Extended Temperature (-20C to 70C)
VPT Wide Voltage with Efficient Switching Power Supply (+9 to +35Vdc)
V Wide Voltage (+9 to +15Vdc)
GW Grey Text / White Background
WB White Text / Blue Background
MSB Most Significant Byte
LSB Least Significant Byte
15.6 Contacting Matrix Orbital
Telephone
Sales: 1(403)229-2737
Support: 1(403)204-3750
Matrix Orbital GLC24064 57
