Description Syntax Page
Write Customer Data Hexadecimal 0xFE 0x34 [data]
Decimal 254 52 [data]
ASCII 254 “4” [data]
45
Read Customer Data Hexadecimal 0xFE 0x35
Decimal 254 53
ASCII 254 “5”
45
14.10 Miscellaneous
Description Syntax Page
Read Version Number Hexadecimal 0xFE 0x36
Decimal 254 54
ASCII 254 “6”
46
Read Module Type Hexadecimal 0xFE 0x37
Decimal 254 55
ASCII 254 “7”
46
14.11 Command By Number
Command Description Page
Hex
Dec ASCII
0x21 33 “!” Wipe Filesystem 38
0x24 36 “$” Uploading a Font File 20
0x30 48 “0” Dump the Filesystem 45
0x31 49 “1” Setting the Current Font 20
0x32 50 “2” Font Metrics 21
0x33 51 “3” Changing the I 2 C Slave Address 14
0x34 52 “4” Write Customer Data 45
0x35 53 “5” Read Customer Data 45
0x36 54 “6” Read Version Number 46
0x37 55 “7” Read Module Type 46
0x39 57 “9” Changing the Baud Rate 15
0x3A 58 “:” Turn Flow Control On 13
0x3B 59 “;” Turn Flow Control Off 14
0x42 66 “B” Display On 34
0x46 70 “F” Display Off 34
0x47 71 “G” Setting the Cursor Position 23
0x48 72 “H” Move Cursor Home 22
0x50 80 “P” Set Contrast 35
0x51 81 “Q” Auto Scroll On 23
0x52 82 “R” Auto Scroll Off 24
0x56 86 “V” General Purpose Output Off 32
