Matrix Orbital GLC24064 - Manual (Page 55)

Description Syntax Page
Draw a Rectangle Hexadecimal 0xFE 0x72 [color] [x1] [y1] [x2] [y2]
Decimal 254 114 [color] [x1] [y1] [x2] [y2]
ASCII 254 “r” [color] [x1] [y1] [x2] [y2]
28
Drawing a Solid
Rectangle Hexadecimal 0xFE 0x78 [color] [x1] [y1] [x2] [y2]
Decimal 254 120 [color] [x1] [y1] [x2] [y2]
ASCII 254 “x” [color] [x1] [y1] [x2] [y2]
28
Initializing a Bar Graph Hexadecimal 0xFE 0x67 [refID] [type] [x1] [y1] [x2] [y2]
Decimal 254 103 [refID] [type] [x1] [y1] [x2] [y2]
ASCII 254 “g” [refID] [type] [x1] [y1] [x2] [y2]
29
Drawing a Bar Graph Hexadecimal 0xFE 0x69 [ref] [value]
Decimal 254 105 [ref] [value]
ASCII 254 “i” [ref] [value]
29
Initializing a Strip Chart Hexadecimal 0xFE 0x6A [refID] [x1] [y1] [x2] [y2]
Decimal 254 106 [refID] [x1] [y1] [x2] [y2]
ASCII 254 “j” [refID] [x1] [y1] [x2] [y2]
30
Shifting a Strip Chart Hexadecimal 0xFE 0x6B [ref]
Decimal 254 107 [ref]
ASCII 254 “k” [ref]
31
14.6 General Purpose Output
Description Syntax Page
General Purpose Output
Off Hexadecimal 0xFE 0x56 [Num]
Decimal 254 86 [Num]
ASCII 254 “V” [Num]
32
General Purpose Output
On Hexadecimal 0xFE 0x57 [Num]
Decimal 254 87 [Num]
ASCII 254 “W” [Num]
32
Set Startup GPO state Hexadecimal 0xFE 0xC3 [Num] [state]
Decimal 254 195 [Num] [state]
33
14.7 Display Functions
Description Syntax Page
Clear Screen Hexadecimal 0xFE 0x58
Decimal 254 88
ASCII 254 “X”
33
Display On Hexadecimal 0xFE 0x42 [min]
Decimal 254 66 [min]
ASCII 254 “B” [min]
34
Display Off Hexadecimal 0xFE 0x46
Decimal 254 70
ASCII 254 “F”
34
Matrix Orbital GLC24064 50
