Description This command shifts the strip chart left or right. [ref] determines both
which strip chart is used and which direction it will shift. The direction
is selected by the most significant bit (MSB):
• MSB: 0 shifts left
• MSB: 1 shifts right
For example if [ref] is 1:
• 254 107 1 (hex FE 6B 01) shifts left
• 254 107 129 (hex FE 6B 81) shifts right
This command shifts the contents of the area defined in the Initialize
Strip Chart command 8 pixels at a time.
Remembered No
9 General Purpose Output
9.1 Introduction
General purpose outputs allow you to connect devices, such as LEDs, to the and supply them with up to
20mA of current at 5V. The has 1 GPO which are software controlled, with functions to turn it on/off and
set the power state for the next startup.
9.2 General Purpose Output Off
Syntax Hexadecimal 0xFE 0x56 [Num]
Decimal 254 86 [Num]
ASCII 254 “V” [Num]
Parameters Parameter Length Description
Num 1 GPO number.
Description This command turns OFF general purpose output [num].
NOTE OFF means that the output is pulled HIGH.
Remembered Yes
9.3 General Purpose Output On
Matrix Orbital GLC24064 32
