6.3
Setting the Cursor Position
Syntax
Hexadecimal
0xFE 0x47 [col] [row]
Decimal
254 71 [col] [row]
ASCII
254 “G” [col] [row]
Parameters
Parameter
Length
Description
col
1
Column
row
1
Row
Description
This command sets the text insertion point to the [col] and [row]
specified. The insertion point is positioned using the base size of the
current font (this command does not position the insertion point at a
specific pixel). The column used is determined by multiplying the width
of the widest character in the font by the [column]. The row used is
determined by multiplying the height of the font by [row + Metrics: line
spacing].
Remembered
No
6.4
Setting the Cursor Coordinate
Syntax
Hexadecimal
0xFE 0x79 [x] [y]
Decimal
254 121 [x] [y]
ASCII
254 “y” [x] [y]
Parameters
Parameter
Length
Description
x
1
The horizontal position in pixels.
y
1
The vertical position in pixels.
Description
This command positions the insertion point at a specific pixel (X,Y),
which references the top left corner of the font insertion point.
Remembered
No
6.5
Auto Scroll On
Syntax
Hexadecimal
0xFE 0x51
Decimal
254 81
ASCII
254 “Q”
Description
When auto scrolling is on, it causes the display to shift the entire
display’s contents up to make room for a new line of text when the text
reaches the end of the scroll row defined in the font metrics (the bottom
right character position) see Section 5.4 on page 22.
Remembered
Yes
