6 filesystem lock jumper – Matrix Orbital GLK240128-25 Legacy User Manual
Page 16

Table 1: Default Values
Contrast
128
Backlight
255
Baud Rate
19.2 kbps
I
2
C Slave Address
0x50
Data Lock
False
RS232AutoTransmitData
True
NOTE
The display module will revert back to the old settings once turned off, unless the
settings are saved.
2.6
Filesystem Lock Jumper
The Filesystem Lock Jumper allows you to lock the filesystem on the GLK240128-25 so that no fonts or
bitmaps can be either written or deleted from the on board memory. This feature is useful in order to protect
data integrity of production units, if protection of other settings is required see Section 12.
To lock the filesystem, solder a zero ohm resistor or use a solder jumper on the Filesystem Lock Jumper
pictured in
figure 18
below, with a lock symbol becide it.
Figure 18: Filesystem Lock Jumper
Matrix Orbital
GLK240128-25
11
