Port
The serial port the display is plugged in to.
Speed
The communication speed the display
module is set to. (Default 19,200)
Display Type
The type of display. (GLK12232-25)
PCB Revision
The revision of the display you are using.
(Found on the back of the PCB)
Figure 10: Mogd Sharp Settings
NOTES
• Winzip is available as a free download from http://www.winzip.com
2
Hardware Information
Refer to the following diagram for this chapter:
Figure 11: GLK12232-25
Matrix Orbital
GLK12232-25
6
