Dimension drawings – Ashcroft GC52 - Rangeable wet/wet Differential Pressure Transmitter User Manual
Page 26
26
Dimension Drawings
Dimensions in inches
1.0
4.49
3.62
2.91
2.28
4.72
5.12
1.97
2.36
.69
2 x Ø .06
Drain
4 x Ø .22
Panel Mounting Holes
Bracket t = .08
Ø 2.56
.42
2.07
Drain Outlet
Equalizing Valve
High Pressure Port
1/4 NPT female
Low Pressure Port
1/4 NPT female
.82
1.42
Electrical Connection PG 13.5
threaded housing, factory installed
options include cable gland or
1/2 FNPT conduit connection
inH
2
O
GC52
14. DIMENSION DRAWINGS
