13
CH+ CH–
GC52
In H
2
O
M
▼ ▲
ባ
Differential pressure
unit monitor
Test Terminals
ብ
MODE key
ቦ
DOWN key ቧ
UP key
ቤ
Scaling - Arbitrary
unit monitor
ቩ
No function
ቢ
Measured data
display
8.8.8.8.8.8.
ቭ Total flow volume
display (X100)
ቮ
Total flow volume
display (X1000)
ቨ
Linear scaling mode
ቫ
Total flow volume
display (X10)
ቪ
Total flow volume
display (X1)
DESIGNATION FUNCTION
➀ Measured data
display
➁ Differential
pressure unit
monitor
➂ Scaling; arbitrary
unit monitor
➃ MODE key
(M)
➄ DOWN key
S
➅ UP key
T
8 8.. DISPLAY FUNCTIONS
Differential pressure, linear scaling value are displayed.
When this unit monitor is ON, the differential pressure (in
H
2
O) is indicated on the measured data display.
When this unit monitor is ON, the scaling value of an arbi-
trary unit (linear scaling), is indicated on the measured
data display.
This key is used to switch the setting mode and the meas-
urement mode and to change the setting item.
This key is used to change (decrease) and select the set
value .
This key is used to change (increase) and select the set
value and to shift from the measurement mode to the zero
adjustment mode.
