9. MODE CHANGES
• Measurement Mode (Section 11 for further detail) will be entered upon
power-on. Setting Mode (Section 13 for further detail) is entered by
pressing and holding the MODE button for more than 3 seconds. If there
is no button operation for 10 minutes in the setting mode, it will shift back
to the Measurement Mode automatically.
• To go from the Measurement Mode to the Zero Adjustment Mode (Sec-
tion 14 for further detail) press and hold the UP T button for more than
3 seconds.
10. POWER-ON MODE
After the power is turned on, the power-on message is displayed for 6
seconds as shown below and then the display is shifted to the measure-
ment mode (section 13). In addition, the analog output during power-on
message is at the zero point (4mA).
8.8.8.8.8.8.
80.0
g[52
Power ON
Power on message
Measurement mode Setting mode Zero adjustment mode
(M) key for more than 3 seconds (▲ ▲ ) key for more than 3 seconds
(M) key for more than 3 seconds or if there
is no operation for 10 minutes
All lights
two seconds
Differential
pressure range
two seconds
Product
Finish
