Specifications, General (applicable to both models) – Ashcroft DM61 User Manual
Page 4
101B224-03 & 101B224-04 Expansion Modules Instruction Manual
4
SPECIFICATIONS
Except where noted all specifications apply to operation at +25°C (77°F).
General (applicable to both models)
POWER
DM61 meter M-LINK connection
CABLE
Standard CAT5e cable; provided with module.
Note: To ensure optimum performance use only supplied
cables.
CONNECTORS
RJ45; identical and interchangeable
Removable screw terminal blocks that accept 12 to 22
AWG wire.
TIGHTENING
TORQUE
Screw terminal connectors: 5 lb-in (0.56 Nm)
ENCLOSURE
ABS-94HB material, UL94HB (Flame-Class Rating)
OVERALL
DIMENSIONS
2.286" x .924" x 3.624" (W x H x D)
58.06 mm x 23.47 mm x 92.05 mm (W x H x D)
101B224-03 4-Relay Expansion Module
RELAYS
Four Form A (SPST); Rated 3 A @ 30 VDC and
125/250 VAC for resistive loads
1/14 HP @ 125/250 VAC for inductive loads.
WEIGHT
2.4 oz (68 g)
