34
7.55
(191.8 mm)
3.00
(76.2 mm)
3.00
(76.2 mm)
12.62 (320.5 mm)
10.42 (264.7 mm)
7.25 (184.1 mm)
2.50
(63.5 mm)
6.75 (171.5 mm)
4 x 1/4-20 UNC-2B 0.35
2 x 1/2 compression fittings
control
valve
CE
50.00
GFC67 MASS FLOW CONTROLLER
NOTE: Aalborg 7 reserves the right to change designs and dimensions at its sole discretion at any
time without notice. For certified dimensions please contact Aalborg 7.
