32
2.69 [68.3]
0.69 [17.5]
3.94 [99.9]
4.88 [123.8]
5.98 [151.8]
FOR HIGH FLOW MASS FLOW CONTROLLER ONLY
6-32
DIMENSIONS: INCH [mm]
2.38
0.95
1.25 [31.8]
0.28 [7.1]
7.33 [186.2]
7.21 [183.1]
0.63 [15.9]
0.63 [15.9]
1.38 [34.9]
5.19 [131.8]
*
*
GFC37/47 MASS FLOW CONTROLLER
NOTE: Aalborg
7 reserves the right to change designs and dimensions at its sole discretion at any
time without notice. For certified dimensions please contact Aalborg
7.
