Figure c-1. sensor location – MagTek MAXI MICR RS232 User Manual
Page 51
Appendix C. Troubleshooting Guide
43
17
Return MICR Reader to MagTek
The MICR Reader has a problem that needs further analysis, testing, and possibly repair. Please
contact the MagTek Help Desk at (451) 651-6800, and make arrangements to send the unit back
to MagTek. Include a detailed description of the problem.
↑
Motor Sensor Data Sensor
→
Figure C-1. Sensor Location
