MAXI MICR RS232 with 2Track MSR
2
•
Encrypting PINPad and Cable, Part Number 30015040 (See Appendix D)
•
Encrypting PINPad Specification, Part Number 99815042
•
Nonencrypting PINPad and Cable, Part Number 30015021 (See Appendix D)
•
Nonencrypting PINPad Technical Description, Part Number 99833004
SPECIFICATIONS
Table 1-1 lists the specifications for the MICR Reader.
Table 1-1. Specifications
OPERATING
Reference Standards ISO/CDL/AAMVA
Power Input 120 VAC, 50/60 Hz
Output Signal Levels 12 VAC, 1 Amp
Check Read/Decode/Transit
Time 1 second
MICR fonts supported E13-B
CMC-7
MSR supported Tracks 1 and 2
MECHANICAL
Dimensions Length 9.25”, Width 4.0”, Height 4.7”
Weight: 3.75 lbs. MSR and Adapter included
Cable length 6’
Connectors DB25 female
ENVIRONMENTAL
Temperature
Operating
0
o
C to 50
o
C (32
o
F to 122
o
F)
Storage -30
o
C to 70
o
C (-22
o
F to 158
o
F)
Humidity
Operating 10% to 90% noncondensing
Storage Up to 100% noncondensing
