37
APPENDIX C. TROUBLESHOOTING GUIDE
REQUIREMENTS
• Personal Computer.
• AC adapter, P/N 64300050.
• SET-MICR program, P/N 22000020.
• Sample checks, P/N 96530005.
• A small bottle of compressed air.
• A cleaning card, P/N 96700006.
SET-UP
1. Plug the DB25 or DB9 connector into the PC.
2. Power on the MICR Reader.
3. Run the SET-MICR program on the PC.
4. Press to establish communication between the PC and the MICR Reader.
5. Start trouble-shooting procedure at Step 00.
00 Check
LED
Check the status of the LED indicator:
◊ off, continue to step 01.
◊ green, continue to step 02.
◊ blinking red, continue to step 11.
◊ blinking green, continue to step 16.
◊ blinking red/green, continue to 12.
◊ red or orange, continue to step 17.
