USB Insertion Reader
48
Example Set Post Card String property Response (Hex):
Result Code Data Len
Data
00
00
Example Get Post Card String property Request (Hex):
Cmd Num
Data Len
Prp ID
00
01
12
Example Get Post Card String property Response (Hex):
Result Code Data Len
Prp Value
00
03
31 32 33
SS TK1 ISO ABA PROPERTY
Property ID:
20 (0x14)
Property Type:
Byte
Length:
1 byte
Get Property:
Yes
Set Property:
Yes
Default Value:
0x25 ‘%’
Description:
This character is sent as the track 1 start sentinel for cards that have track 1
encoded in ISO/ABA format. If the value is 0 no character is sent. If the
value is in the range 1 – 127 then the equivalent ASCII character will be sent.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled to have these changes take effect.
SS TK2 ISO ABA PROPERTY
Property ID:
21 (0x15)
Property Type:
Byte
Length:
1 byte
Get Property:
Yes
Set Property:
Yes
Default Value:
0x3B ‘;’
Description:
This character is sent as the track 2 start sentinel for cards that have track 2
encoded in ISO/ABA format. If the value is 0 no character is sent. If the
value is in the range 1 – 127 then the equivalent ASCII character will be sent.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled to have these changes take effect.
