FEATURES
Major features of the Insert Reader are as follows:
•
Powered through the USB – no external power supply required (current consumption of less
than one USB Unit Load)
•
Hardware Compatible with PC or any computer or terminal with a USB interface
•
Mag-Stripe reading during insertion and/or removal of card – for reliable card reading
•
Reads encoded data that meets ANSI/ISO/AAMVA standards and other custom formats such
as ISO track 1 format on track 2 or 3
•
Reads up to three tracks of card data
•
Compatible with USB specification Revision 1.1
•
Compatible with HID specification Version 1.1
•
Can use standard Windows HID driver for communications; no third party device driver is
required
•
Programmable USB serial number descriptor
•
Programmable USB Interrupt In Endpoint polling interval
•
Programmable read direction. (insert, withdrawal or both)
•
Non-volatile memory for configuration storage
•
Optional 6-foot Black or Pearl White cable; the 3-track version uses standard USB mini Type
B connector
•
Isolated PCB – isolates electronics from debris and liquids
•
AGC (Automatic Gain Control) in MagTek’s latest read IC - enhances read performance
with less susceptibility to RF interference
•
Beam-mounted Read-heads – improves card tracking capabilities
•
Ruggedized Chassis and Bezel Material - improves temperature and impact performance
•
Open Chassis Design – provides superior debris clearing capability
•
Half-card Drop Out – allows half-size credit cards and coins to be cleared from insert
channel.
HARDWARE CONFIGURATIONS
The Configuration is as follows:
Part
Number
Head
Configuration
USB
Mode
Bezel Connector Cable P/N
21065140 Dual head, Tk 1,2,3 HID/KB Flat
USB Mini B,
5-pin
16051430
21065141 Dual head, Tk 1,2 HID Extended 53048-0510 21041494 or 21041495
21065145 Head right, Tk 1,2,3 HID/KB None
USB Mini B,
5-pin
16051430
21065146 Dual head, Tk 1,2 HID None 53048-0510 21041494 or 21041495
21065150 Dual head, Tk 1,2,3 KB Flat
USB Mini B,
5-pin
16051430
21065154 Dual head, Tk 1,2,3 HID Flat
USB Mini B,
5-pin
16051430
