USB Insertion Reader
14
The device will go into suspend mode when directed to do so by the host. The device will
wakeup from suspend mode when directed to do so by the host. The device does not support
remote wakeup.
This device is powered from the USB bus. Its vendor ID is 0x0801 and its product ID is 0x0003.
HID USAGES
HID devices send data in reports. Elements of data in a report are identified by unique identifiers
called usages. The structure of the device’s reports and the device’s capabilities are reported to
the host in a report descriptor. The host usually gets the report descriptor only once, right after
the device is plugged in. The report descriptor usages identify the devices capabilities and report
structures. For example, a device could be identified as a keyboard by analyzing the device’s
report descriptor. Usages are four byte integers. The most significant two bytes are called the
usage page and the least significant two bytes are called usage IDs. Usages that are related can
share a common usage page. Usages can be standardized or they can be vendor defined.
Standardized usages such as usages for mice and keyboards can be found in the HID Usage
Tables document and can be downloaded free at www.usb.org. Vendor defined usages must
have a usage page in the range 0xff00 – 0xffff. All usages for this device use vendor defined
magnetic stripe reader usage page 0xff00. The usage IDs for this device are defined in the
following table. The usage types are also listed. These usage types are defined in the HID
Usage Tables document.
Magnetic Stripe Reader usage page 0xff00:
Usage ID
(Hex)
Usage Name
Usage
Type
Report
Type
1
Decoding reader device
Collection
None
20
Track 1 decode status
Data
Input
21
Track 2 decode status
Data
Input
22
Track 3 decode status
Data
Input
28
Track 1 data length
Data
Input
29
Track 2 data length
Data
Input
2A
Track 3 data length
Data
Input
30
Track 1 data
Data
Input
31
Track 2 data
Data
Input
32
Track 3 data
Data
Input
38
Card encode type
Data
Input
39
Card status
Data
Input
20
Command message
Data
Feature
