Section 5. USB Communications (KB)
39
TRACK ID ENBLE PROPERTY
Property ID: 27 (0x1B)
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 0x95
Description: This property is defined as follows:
id 0 T
3
T
3
T
2
T
2
T
1
T
1
Id 0 – Decodes standard ISO/ABA cards only
1 – Decodes AAMVA, CA DL/ID and 7-bit cards also
T
#
00 – Track Disabled
01 – Track Enabled
10 – Track Enabled/Required (Error if blank)
This property is stored in non-volatile memory, so it will persist when the unit is
power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled to have these changes take effect.
Example Set Track ID Enable property Request (Hex):
Cmd Num Data Len Prp ID Prp Value
01 02 1B 95
Example Set Track ID Enable property Response (Hex):
Result Code Data Len Data
00 00
Example Get Track ID Enable property Request (Hex):
Cmd Num Data Len Prp ID
00 01 1B
Example Get Track ID Enable property Response (Hex):
Result Code Data Len Prp Value
00 01 95
TRACK DATA SEND FLAGS PROPERTY
Property ID: 26 (0x1A)
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 0x63
