USB Insertion Reader
36
Property ID is a one-byte field that contains a value that identifies the property. The following
table lists all the current property ID values:
Value Property ID Description
0 SOFTWARE ID The device’s software identifier
1 SERIAL NUM The device’s serial number
2 POLLING INTERVAL The interrupt pipe’s polling interval
27 TRACK ID ENABLE Track enable / ID enable
26 TRACK DATA SEND FLAGS Track data send flags
5 TERMINATION CHAR Terminating char / per track or card flag
6 SS TK2 7BITS Start sentinel char for track 2 – 7 bit data
7 Reserved for future use
8 SS TK3 ISO ABA Start sentinel char for track 3 – ISO/ABA
9 SS TK3 AAMVA Start sentinel char for track 3 - AAMVA
10 SS TK3 7BITS Start sentinel char for track 3 – 7 bit data
11 PRE CARD CHAR Pre card char
12 POST CARD CHAR Post card char
13 PRE TK CHAR Pre track char
14 POST TK CHAR Post track char
15
ASCII TO KEYPRESS
CONVERSION TYPE Type of conversion performed when
converting ASCII data to key strokes
16 INTERFACE TYPE Type of USB interface
17 ACTIVE KEYMAP Selects which key map to use
18 PRE CARD STRING Pre card string
19 POST CARD STRING Post card string
20 SS TK1 ISO ABA Start sentinel char for track 1 – ISO/ABA
21 SS TK2 ISO ABA Start sentinel char for track 2 – ISO/ABA
22 ES End sentinel char for all tracks/formats
3 MSR DIRECTION Magnetic stripe read direction
4 CARD INSERTED Card inserted indicator
28 SENSOR BLOCKED CHAR Sensor blocked char
29 SENSOR UNBLOCKED CHAR Sensor unblocked char
23 ES TK1 End sentinel char for track 1
24 ES TK2 End sentinel char for track 2
25 ES TK3 End sentinel char for track 3
The Property Value is a multiple-byte field that contains the value of the property. The number
of bytes in this field depends on the type of property and the length of the property. The
following table lists all of the property types and describes them.
Property Type Description
Byte
This is a one-byte value. The valid values depend on the property.
String This is a multiple byte ASCII string. Its length can be zero to a
maximum length that depends on the property. The value and
length of the string does not include a terminating NUL character.
SOFTWARE ID PROPERTY
Property ID: 0
Property Type: String
Length: Fixed at 11 bytes
Get Property: Yes
