MagTek USB INSERTION READER - Manual (Page 2)

ii
Copyright
©
2001-2012
MagTek
®
, Inc.
Printed in the United States of America
Information in this document is subject to change without notice. No part of this document may be
reproduced or transmitted in any form or by any means, electronic or mechanical, for any purpose,
without the express written permission of MagTek, Inc.
MagTek is a registered trademark of MagTek, Inc.
USB (Universal Serial Bus) Specification is Copyright© 1998 by Compaq Computer Corporation, Intel
Corporation, Microsoft Corporation, NEC Corporation.
REVISIONS
Rev Number Date Notes
1 29 Oct 01 Initial Release
2 13 Nov 01 Changed Temp Spec: Operating: 0
o
to 65
o
C (32
o
to 149
o
F), and
Storage: -40
o
to 80
o
C (-40
o
to 176
o
F)
3 12 Dec 02 Section 4, Command Number: Corrected GET and SET PROPERTY
descriptions
4 28 Jan 03 Changed copyright symbol so pdf copies would print on all printers
5 03 Jun 03 Front Matter: added ISO line to logo, changed Tech Support phone
number, added new warranty statement.
6 16 Jul 03 Sec 4: In the paragraph beginning “This device is powered…”
changed Product ID from 0x0002 to 0x0003.
7 30 May 06 Removed reference to JIS. Changed to 3-track reading capability.
Added Reset, LED and Track Enable commands. Added description
on reader LED operation. New top level reader part number
21065140. Updated temperature and swipe speed ranges.
8 13 Sep 06 Updated Configuration Table: added 21065141; included type of
bezel and cable P/N
9 9 Oct 07 Added keyboard emulation feature; added part numbers 21065145 &
21065146
10 6 Jun 08 Corrected reverences from “swipe” to “insert” reader; added RoHS
statement
11 13 Aug 08 Added 21065150; included Molex connector information for older
reader models; included connector descriptions for both models
12 19 Oct 10 Removed 21065099; Added 21065154; removed reference to LED.
13 3 May 12 Updated images to improve quality.
