P-Series USB Insertion Reader
50
Example Set Sensor Blocked Char property Response (Hex):
Result Code Data Len Data
00 00
Example Get Sensor Blocked Char property Request (Hex):
Cmd Num Data Len Prp ID
00 01 1C
Example Get Sensor Blocked Char property Response (Hex):
Result Code Data Len Prp Value
00 01 31
SENSOR UNBLOCKED CHAR
Property ID:
29 (0x1D)
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 0
Description: This character is sent in the sensor field of the card data when the sensor is
unblocked. If the value is 0 no character is sent. If the value is in the range 1
– 127 then the equivalent ASCII character will be sent.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled to have these changes take effect.
Examples follow:
Example Set Sensor Unblocked Char property to ASCII “0” Request (Hex):
Cmd Num Data Len Prp ID Prp Value
01 02 1D 30
Example Set Sensor Unblocked Char property Response (Hex):
Result Code Data Len Data
00 00
Example Get Sensor Unblocked Char property Request (Hex):
Cmd Num Data Len Prp ID
00 01 1D
Example Get Sensor Unblocked Char property Response (Hex):
Result Code Data Len Prp Value
00 01 30
