P-Series USB Insertion Reader
48
MSR DIRECTION PROPERTY
Property ID:
3 (0x03)
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 2 (Withdrawal)
Description: This value is a byte that represents the devices magnetic stripe read direction.
The device will output card data when a card is swiped in the direction
indicated by this property. The value can be set to 1 for insert, 2 for
withdrawal or 3 for both directions. This property is stored in non-volatile
EEPROM memory so it will not change when the unit is power cycled. When
this property is changed, the unit must be power cycled to have these changes
take effect. If a value other than the default value is desired, it can be set by
the factory upon request.
Note that this reader reads better when a card is removed from it than when a
card is inserted into it.
Examples follow:
Example Set MSR Direction property Request (Hex):
Cmd Num Data Len Prp ID Prp Value
01 02 03 02
Example Set MSR Direction property Response (Hex):
Result Code Data Len Data
00 00
Example Get MSR Direction property Request (Hex):
Cmd Num Data Len Prp ID
00 01 03
Example Get MSR Direction property Response (Hex):
Result Code Data Len Prp Value
00 01 02
